MIRU-VNTR genotyping and clustering of Mycobacterium tuberculosis isolates in Yichang

doi:10.3969/j.issn.1000-6621.2019.03.012

Abstract

Abstract:

Objective To determine the genotypes and clustering patterns of Mycobacterium tuberculosis in Yichang and provide evidence for use in the prevention and treatment of tuberculosis.Methods Sputum samples determined to be positive for Mycobacterium tuberculosis using gene microarrays were collected in Yichang from December 2016 to May 2017. After culturing in Roche medium, 367 Mycobacterium tuberculosis isolates were genotyped using the internationally recognised 24 locus MIRU-VNTR system, and the resolution and variation of the MIRU locus was evaluated using the Hunter-Gaston index (HGI) and genetic difference value (h). MIRU-VNTR results were analyzed using BioNumerics 5.0 software to calculate recent transmission rates. The study population of 367 strains, isolated from 367 patients, was subdivided into 321 strains isolated from new TB cases and 46 strains from relapsed cases. Clustering rates were analysed separately for each set of strains. The clustering rates for new and retreated cases were compared using the chi-square test. P<0.05 was considered statistically significant.Results Genotyping of the 367 M.tuberculosis strains using the 24 locus MIRU-VNTR system gave an HGI value of 0.999. The locus with the highest genetic diversity was QUB11b, with an h value of 0.79, and that with the lowest genetic diversity was MIRU24, with an h value of 0.03. A total of 324 genotypes were identified, polymorphisms being evident. Results from clustering analysis indicated that 90 strains formed 39 clusters, with a clustering rate of 24.52% (90/367) and the recent transmission rate of 13.90% (51/367). The clustering rate of strains from relapsed cases (21.74%, 10/46) was not significantly different from that for strains isolated from new cases (24.92%, 80/321) (χ²=0.220, P=0.639).Conclusion Tuberculosis cases in the Yichang area showed high genetic diversity and low transmission rates. Clustering rates were not linked to whether cases were new or relapsed cases.Results suggest that the majority of tuberculosis cases in Yichang are due to endogenous activation. There is also a limited amount of local transmission. Greater attention should be paid to tuberculosis prevention and control in Yichang.

Key words: Mycobacterium tuberculosis, Genotype, Tandem repeat sequences, Sequence tagged sites, Cluster analysis

Xiao-jun LIU,Feng-hua YU,Yun-fang YU,L-yu JI,Pan ZHOU,Yan-lin ZHAO. MIRU-VNTR genotyping and clustering of Mycobacterium tuberculosis isolates in Yichang[J]. Chinese Journal of Antituberculosis, 2019, 41(3): 308-314. doi: 10.3969/j.issn.1000-6621.2019.03.012

Figures/Tables 6

References 21

[1]	World Health Organization. Golobal tuberculosis report 2018. Geneva: World Health Organization, 2018.
[2]	代旭磊, 柳爱华, 宝福凯 , 等. 结核分枝杆菌的分子分型技术研究进展. 临床检验杂志, 2011,11(29):69-611. doi: 10.1038/cdd.2010.68 URL
[3]	Shi J, Zheng D, Zhu Y , et al. Role of MIRU-VNTR and spoligotyping in assessing genetic diversity of Mycobacterium tuberculosis in Henan Province,China. BMC Infect Dis, 2018,18(1):447. doi: 10.1186/s12879-018-3351-y URL
[4]	Dickman KR, Nabyonga L, Kateete DP , et al. Detection of multiple strains of Mycobacterium tuberculosis using MIRU-VNTR in patients with pulmonary tubeculosis in Kampala, Uganda. BMC Infect Dis, 2010,349(10):1-8. doi: 10.1186/1471-2334-10-349 URL pmid: 21143966
[5]	Mears J, Abubakar I, Cohen T , et al. Effect of study design and setting on tuberculosis clustering estimates using mycobacterial interspersed repetitive units-variable number tandem repeats (MIRU-VNTR): a systematic review. BMJ Open, 2015,5(1):e005636. doi: 10.1136/bmjopen-2014-005636 URL pmid: 4305070
[6]	Supply P, Allix C, Lesjean S , et al. Proposal for standardization of optimized mycobecterial interspersed repetitive unit-variable-number tadnem repeat typping of Mycobacterium tuberculosis. Clin Microbiol, 2006,44(12):4498-4510. doi: 10.1128/JCM.01392-06 URL
[7]	Selander RK, Caugant DA, Ochman H , et al. Methods of multilocus enzyme electrophoresis for bacterial population genetics and systematics. Appl Environ Microbiol, 1986,51(5):873-884.
[8]	Flores-Trevino S, Morfin-Otero R, Rodriguez-Noriega E , et al. Genetic diversity of Mycobacterium tuberculosis from Guadalajara, Mexico and identification of a rare multidrug resistant Beijing genotype. PLoS One, 2015,10(2):e0118095. doi: 10.1371/journal.pone.0118095 URL pmid: 4335057
[9]	Mokrousov I, Narvskaya O, Limeschenko E , et al. Analysis of the allelic diversity of the mycobacterial interspersed repetitive units in Mycobacterium tuberculosis strains of the Beijing family: practical implications and evolutionary considerations. J Clin Microbiol, 2004,42(6):2438-2444. doi: 10.1128/JCM.42.6.2438-2444.2004 URL pmid: 15184416
[10]	Mathuria JP, Anupurba S . Usefulness of IS6110-based restriction fragment length polymorphism analysis in fingerprinting of Mycobacterium tuberculosis isolates in North India. Int J Mycobacterio, 2016,5 Suppl 1: S176-177. doi: 10.1016/j.ijmyco.2016.10.041 URL pmid: 28043537
[11]	Luo T, Comas I, Luo D , et al. Southern East Asia origin and coexpansion of Mycobacterium tuberculosis Beijing family with Han Chinese. Proc Natl Acad Sci U S A, 2015,112(26):8136-8141. doi: 10.1073/pnas.1424063112 URL pmid: 26080405
[12]	徐鹏, 甘明宇, 高谦 . 二代测序在结核分枝杆菌中的应用进展. 微生物与感染, 2015,10(1):54-60.
[13]	Walker TM, Monk P, Smith PG , et al. Contact investigations for outbreaks of Mycobacterium tuberculosis: advances through whole gene sequencin. Clin Microbiol Infect, 2013,19(9):796-802. doi: 10.1111/1469-0691.12183 URL pmid: 23432709
[14]	林桂伟, 王永林 . 仙居县80株结核分枝杆菌临床分离株VNTR基因分型技术研究. 中国卫生检验杂志, 2015,25(6):886-869.
[15]	van Deutekom H, Supply P, de Haas PE , et al. Molecular typing of Mycobacerium tuberculosis by mycobacterial interspersed repetitive unit-variable-number tandem repeat analysis, a more accurate method for identifying epidemiological links between patients with tuberculosis. J Clin Microbiol, 2005,43(9):4473-4479. doi: 10.1128/JCM.43.9.4473-4479.2005 URL pmid: 16145094
[16]	Hamblion EL, Le Menach A, Anderson LF , et al. Recent TB transmission, Clustering and predictors of large clusters in London, 2010-2012: results from first 3 years of universal MIRU-VNTR strain typing. Thorax, 2016,71(8):749-756. doi: 10.1136/thoraxjnl-2014-206608 URL pmid: 27417280
[17]	陈志, 陈佳, 李六林 , 等. 应用VNTR技术对绵阳地区结核分枝杆菌进行基因分型. 中华疾病控制杂志, 2011,15(9):810-813.
[18]	Gonzalez Diaz A, Battaglioli T, Diaz Rodriuez R , et al. Molecular epidemiology of tuberculosis in Havana, Cuba, 2009. Trop Med Int Health, 2015,20(11):1534-1542. doi: 10.1111/tmi.12569 URL pmid: 26211409
[19]	Inigo J, Garcia de Viedma D, Arce A , et al. Analysis of changes in recent tuberculosis transmission patterns after a sharp increase in immigration. J Clin Microbio, 2007,45(1):63-69. doi: 10.1128/JCM.01644-06 URL pmid: 1828995
[20]	徐贵生 . 连云港市结核杆菌分子分型及其与临床特征的关联研究. 南京:南京医科大学公共卫生学院, 2017.
[21]	张志, 李雅楠, 高会霞 , 等. 邢台地区275株结核分枝杆菌VNTR基因分型及表型耐药研究. 临床肺科杂志, 2017,22(10):1884-1888. doi: 10.3969/j.issn.1009-6663.2017.010.037 URL

位点	h值	HGI值
MIRU02	0.043	0.042
Mtub04	0.065	0.064
ETRC	0.072	0.071
MIRU04	0.294	0.293
MIRU40	0.536	0.535
MIRU10	0.536	0.535
MIRU16	0.473	0.472
Mtub21	0.791	0.790
MIRU20	0.264	0.263
位点	h值	HGI值
QUB11b	0.791	0.790
Mtub29	0.512	0.511
Mtub29	0.086	0.085
Mtub30	0.453	0.452
ETRB	0.287	0.286
MIRU23	0.072	0.071
MIRU24	0.032	0.031
MIRU26	0.735	0.734
MIRU27	0.258	0.257
Mtub34	0.082	0.081
MIRU31	0.554	0.553
Mtub39	0.082	0.081
QUB26	0.635	0.634
QUB4156	0.311	0.310
MIRU39	0.516	0.515
总分辨率	-	0.999

患者类别	菌株数	成簇菌株数	OR(95%CI)值	χ²值	P值
复治	46	10(21.74)	1.000	0.220	0.639
初治	321	80(24.92)	1.195(0.567~2.517)
合计	367	90(24.52)
