Chinese Journal of Antituberculosis ›› 2023, Vol. 45 ›› Issue (10): 957-966.doi: 10.19982/j.issn.1000-6621.20230141
• Original Articles • Previous Articles Next Articles
Chen Daiquan, Lin Shufang, Dai Zhisong, Zhou Yinfa, Chen Kun()
Received:
2023-05-04
Online:
2023-10-10
Published:
2023-10-07
Contact:
Chen Kun, Email: Supported by:
CLC Number:
Chen Daiquan, Lin Shufang, Dai Zhisong, Zhou Yinfa, Chen Kun. Construction and validation of a nomogram for predicting unfavorable treatment outcomes among patients with rifampicin-sensitive tuberculosis[J]. Chinese Journal of Antituberculosis, 2023, 45(10): 957-966. doi: 10.19982/j.issn.1000-6621.20230141
Add to citation manager EndNote|Ris|BibTeX
URL: http://www.zgflzz.cn/EN/10.19982/j.issn.1000-6621.20230141
特征 | 总体(75063例) | 训练集(37532例) | 验证集(37531例) | 统计检验值 | P值 | |
---|---|---|---|---|---|---|
性别[例数(构成比,%)] | χ2=0.538 | 0.463 | ||||
男性 | 55151(73.47) | 27531(73.35) | 27620(73.59) | |||
女性 | 19912(26.53) | 10001(26.65) | 9911(26.41) | |||
年龄(岁,$\bar{x} \pm s$) | 48.09±17.69 | 48.13±17.75 | 48.06±17.64 | t=0.496 | 0.620 | |
民族[例数(构成比,%)] | χ2=2.560 | 0.110 | ||||
汉族 | 73581(98.03) | 36760(97.94) | 36821(98.11) | |||
少数民族 | 1482(1.97) | 772(2.06) | 710(1.89) | |||
职业[例数(构成比,%)] | χ2=2.420 | 0.789 | ||||
企事业单位 | 1946(2.59) | 942(2.51) | 1004(2.68) | |||
学生及儿童 | 2824(3.76) | 1413(3.77) | 1411(3.76) | |||
公共场所及商业服务 | 2554(3.40) | 1292(3.44) | 1262(3.36) | |||
体力劳动 | 45169(60.18) | 22578(60.16) | 22591(60.19) | |||
退休和待业 | 17927(23.88) | 8982(23.93) | 8945(23.83) | |||
职业不详 | 4643(6.19) | 2325(6.19) | 2318(6.18) | |||
现住址类型[例数(构成比,%)] | χ2=0.387 | 0.534 | ||||
本县区 | 57462(76.55) | 28768(76.65) | 28694(76.45) | |||
非本县区 | 17601(23.45) | 8764(23.35) | 8837(23.55) | |||
户籍地址类型[例数(构成比,%)] | χ2=0.002 | 0.967 | ||||
本地 | 48449(64.54) | 24228(64.55) | 24221(64.54) | |||
外地 | 26614(35.46) | 13304(35.45) | 13310(35.46) | |||
现住址所属地市[例数(构成比,%)] | χ2=13.477 | 0.096 | ||||
福州市 | 14371(19.15) | 7183(19.14) | 7188(19.15) | |||
厦门市 | 7873(10.49) | 3926(10.46) | 3947(10.52) | |||
莆田市 | 5686(7.57) | 2808(7.48) | 2878(7.67) | |||
三明市 | 4155(5.54) | 2049(5.46) | 2106(5.61) | |||
泉州市 | 18915(25.20) | 9442(25.16) | 9473(25.24) | |||
漳州市 | 8943(11.91) | 4434(11.81) | 4509(12.01) | |||
南平市 | 4757(6.34) | 2486(6.62) | 2271(6.05) | |||
龙岩市 | 4898(6.52) | 2432(6.48) | 2466(6.57) | |||
宁德市 | 5465(7.28) | 2772(7.39) | 2693(7.18) | |||
患者发现方式[例数(构成比,%)] | χ2=1.699 | 0.192 | ||||
主动发现 | 859(1.14) | 449(1.20) | 410(1.09) | |||
被动发现 | 74204(98.86) | 37083(98.80) | 37121(98.91) | |||
合并症[例数(构成比,%)] | χ2=0.401 | 0.526 | ||||
无 | 66525(88.63) | 33291(88.70) | 33234(88.55) | |||
有 | 8538(11.37) | 4241(11.30) | 4297(11.45) | |||
治疗分类[例数(构成比,%)] | χ2=1.189 | 0.275 | ||||
初治 | 70545(93.98) | 35309(94.08) | 35236(93.89) | |||
复治 | 4518(6.02) | 2223(5.92) | 2295(6.11) | |||
初诊痰菌结果[例数(构成比,%)] | χ2=0.536 | 0.464 | ||||
阴性 | 42170(56.18) | 21035(56.05) | 21135(56.31) | |||
阳性 | 32893(43.82) | 16497(43.95) | 16396(43.69) | |||
合并其他部位结核[例数(构成比,%)] | χ2=0.727 | 0.394 | ||||
否 | 68291(90.98) | 34112(90.89) | 34179(91.07) | |||
是 | 6772(9.02) | 3420(9.11) | 3352(8.93) | |||
治疗转归[例数(构成比,%)] | χ2=0.084 | 0.772 | ||||
成功治疗 | 68191(90.85) | 34084(90.81) | 34107(90.88) | |||
不良转归 | 6872(9.15) | 3448(9.19) | 3424(9.12) |
因素 | 转归良好(34084例) | 转归不良(3448例) | 统计检验值 | P值 |
---|---|---|---|---|
性别[例数(构成比,%)] | χ2=101.526 | <0.001 | ||
男性 | 24752(72.62) | 2779(80.60) | ||
女性 | 9332(27.38) | 669(19.40) | ||
年龄(岁,$\bar{x} \pm s$) | 47.28±17.54 | 56.53±17.63 | t=29.379 | <0.001 |
民族[例数(构成比,%)] | χ2=2.446 | 0.118 | ||
汉族 | 33370(97.91) | 3390(98.32) | ||
少数民族 | 714(2.09) | 58(1.68) | ||
职业[例数(构成比,%)] | χ2=171.953 | <0.001 | ||
企事业单位 | 902(2.65) | 40(1.16) | ||
学生及儿童 | 1390(4.08) | 23(0.67) | ||
公共场所及商业服务 | 1216(3.57) | 76(2.20) | ||
体力劳动 | 20357(59.72) | 2221(64.41) | ||
退休和待业 | 8067(23.67) | 915(26.54) | ||
职业不详 | 2152(6.31) | 173(5.02) | ||
现住址类型[例数(构成比,%)] | χ2=2.803 | 0.094 | ||
本县区 | 26085(76.53) | 2683(77.81) | ||
非本县区 | 7999(23.47) | 765(22.19) | ||
户籍地址类型[例数(构成比,%)] | χ2=23.123 | <0.001 | ||
本地 | 21873(64.17) | 2355(68.30) | ||
外地 | 12211(35.83) | 1093(31.70) | ||
患者发现方式[例数(构成比,%)] | χ2=9.498 | 0.002 | ||
主动发现 | 427(1.25) | 22(0.64) | ||
被动发现 | 33657(98.75) | 3426(99.36) | ||
合并症[例数(构成比,%)] | χ2=33.730 | <0.001 | ||
无 | 30336(89.00) | 2955(85.70) | ||
有 | 3748(11.00) | 493(14.30) | ||
治疗分类[例数(构成比,%)] | χ2=190.426 | <0.001 | ||
初治 | 32248(94.61) | 3061(88.78) | ||
复治 | 1836(5.39) | 387(11.22) | ||
初诊痰菌结果[例数(构成比,%)] | χ2=47.269 | <0.001 | ||
阴性 | 19294(56.61) | 1741(50.49) | ||
阳性 | 14790(43.39) | 1707(49.51) | ||
合并其他部位结核[例数(构成比,%)] | χ2=2.351 | 0.125 | ||
无 | 30953(90.81) | 3159(91.62) | ||
有 | 3131(9.19) | 289(8.38) | ||
现住址所属地市[例数(构成比,%)] | χ2=219.836 | <0.001 | ||
福州市 | 6509(19.10) | 674(19.55) | ||
厦门市 | 3680(10.79) | 246(7.13) | ||
莆田市 | 2416(7.09) | 392(11.37) | ||
三明市 | 1874(5.50) | 175(5.08) | ||
泉州市 | 8537(25.05) | 905(26.25) | ||
漳州市 | 3957(11.61) | 477(13.83) | ||
南平市 | 2350(6.89) | 136(3.94) | ||
龙岩市 | 2157(6.33) | 275(7.98) | ||
宁德市 | 2604(7.64) | 168(4.87) |
因素 | β值 | s | Wald χ2值 | P值 | OR(95%CI)值 |
---|---|---|---|---|---|
女性 | -0.259 | 0.046 | 31.672 | <0.001 | 0.772(0.705~0.845) |
年龄 | 0.027 | 0.001 | 492.773 | <0.001 | 1.028(1.025~1.030) |
职业(以“企事业单位职工”为参考水平) | |||||
学生及儿童 | -0.356 | 0.267 | 1.771 | 0.183 | 0.701(0.415~1.183) |
公共场所及商业服务 | 0.403 | 0.202 | 3.981 | 0.046 | 1.496(1.007~2.223) |
体力劳动 | 0.363 | 0.166 | 4.808 | 0.028 | 1.438(1.039~1.989) |
退休和待业 | 0.553 | 0.168 | 10.825 | 0.001 | 1.738(1.250~2.416) |
职业不详 | 0.506 | 0.182 | 7.737 | 0.005 | 1.658(1.161~2.369) |
外地户籍 | 0.077 | 0.045 | 3.005 | 0.083 | 1.080(0.990~1.179) |
有合并症 | 0.102 | 0.054 | 3.570 | 0.059 | 1.108(0.996~1.232) |
复治 | 0.594 | 0.061 | 94.444 | <0.001 | 1.810(1.606~2.041) |
初诊痰菌阳性 | 0.073 | 0.037 | 3.793 | 0.051 | 1.075(1.000~1.157) |
现住址所属地市(以“福州市”为参考水平) | |||||
厦门市 | -0.195 | 0.079 | 6.045 | 0.014 | 0.823(0.704~0.961) |
莆田市 | 0.499 | 0.076 | 43.304 | <0.001 | 1.647(1.420~1.911) |
三明市 | -0.050 | 0.095 | 0.283 | 0.595 | 0.951(0.790~1.145) |
泉州市 | 0.177 | 0.061 | 8.486 | 0.004 | 1.194(1.060~1.345) |
漳州市 | 0.147 | 0.070 | 4.366 | 0.037 | 1.158(1.009~1.329) |
南平市 | -0.560 | 0.102 | 29.841 | <0.001 | 0.571(0.468~0.699) |
龙岩市 | 0.234 | 0.083 | 7.892 | 0.005 | 1.264(1.073~1.488) |
宁德市 | -0.355 | 0.094 | 14.263 | <0.001 | 0.701(0.583~0.843) |
[1] | World Health Organization. Global tuberculosis report 2022. Geneva: World Health Organization, 2022. |
[2] | 黄建英, 钟球, 周琳, 等. 中国肺结核治疗失败影响因素的Meta 分析. 中华疾病控制杂志, 2014, 18(2): 102-107. |
[3] | 肖月, 饶正远, 夏岚, 等. 2011—2015年四川省涂阴肺结核流行特征与治疗转归结果分析. 预防医学情报杂志, 2018, 34(9): 1135-1141. |
[4] | 蒋远东, 马志, 腾子豪, 等. 2010—2019年新疆伊宁市初治涂阳肺结核患者流行特征及治疗转归分析. 现代预防医学, 2021, 48(23): 4234-4239. |
[5] | 龚新记, 文进, 李月华, 等. 3071例成人新登记涂阳肺结核患者治疗结局分析. 新疆医科大学学报, 2020, 43(11): 1514-1517. doi:10.3639/j.issn.1009-5551.2020.11.025. |
[6] | 黎永华, 李朝勇, 黄隆. 三亚市老年肺结核患者治疗失败的影响因素调查分析. 中国卫生统计, 2017, 34(1): 85-86, 90. |
[7] | 尤莉莉, 陈新月, 杨凌鹤, 等. 国家基本公共卫生服务项目实施十年:挑战与建议. 中国全科医学, 2022, 25(26): 3221-3231. doi:10.12114/j.issn.1007-9572.2022.0406. |
[8] | 刘小秋. 我国肺结核患者治疗管理的若干意见. 中国防痨杂志, 2019, 41(9): 917-919. doi:10.3969/j.issn.1000-6621.2019.09.002. |
[9] | 李本春, 王应军, 曹晓玉. 肺结核患者服药依从性预测模型的建立. 现代医学, 2022, 50(5): 529-535. doi:10.3969/j.issn.1671-7562.2022.05.001. |
[10] | 李颜玲, 陈洁, 徐梦云, 等. 肺结核患者治疗不成功风险预测模型的构建与验证[J/OL]. 中国预防医学杂志, 2023: 1-9 [2023-04-04]. http://kns.cnki.net/kcms/detail/11.4529.r.20230217.1656.010.html. [网络预发表]. |
[11] |
Yan H, Guo L, Pang Y, et al. Clinical characteristics and predictive model of pulmonary tuberculosis patients with pulmonary fungal coinfection. BMC Pulm Med, 2023, 23(1):56. doi:10.1186/s12890-023-02344-4.
pmid: 36750804 |
[12] | Riley RD, Ensor J, Snell KIE, et al. Calculating the sample size required for developing a clinical prediction model. BMJ, 2020, 368:m441. doi:10.1136/bmj.m441. |
[13] | 中华人民共和国卫生健康委员会. 中国结核病预防控制工作技术规范(2020年版). 国卫办疾控函〔2020〕279号. 2020-09-14. |
[14] | Peetluk LS, Ridolfi FM, Rebeiro PF, et al. Systematic review of prediction models for pulmonary tuberculosis treatment outcomes in adults. BMJ Open, 2021, 11(3):e044687. doi:10.1136/bmjopen-2020-044687. |
[15] | 梁达, 赵晓银, 商越, 等. 青海省结核病患者治疗结局影响因素分析及贝叶斯网络模型研究. 疾病监测, 2022, 37(2): 210-213. doi:10.3784/jbjc.202103230151. |
[16] | Chaves Torres NM, Quijano Rodríguez JJ, Porras Andrade PS, et al. Factors predictive of the success of tuberculosis treatment: A systematic review with meta-analysis. PLoS One, 2019, 14(12):e0226507. doi:10.1371/journal.pone.0226507. |
[17] | 闫银锁, 许琰, 倪新兰, 等. 肺结核患者治疗结局影响因素多水平模型分析. 中国卫生统计, 2021, 38(1): 25-27. doi:10.3969/j.issn.1002-3674.2021.01.007. |
[18] | Peetluk LS, Rebeiro PF, Ridolfi FM, et al. A Clinical Prediction Model for Unsuccessful Pulmonary Tuberculosis Treatment Outcomes. Clin Infect Dis, 2022, 74(6):973-982. doi:10.1093/cid/ciab598. |
[19] |
Vickers AJ, Elkin EB. Decision curve analysis: a novel method for evaluating prediction models. Med Decis Making, 2006, 26(6):565-574. doi:10.1177/0272989X06295361.
pmid: 17099194 |
[20] |
Mehralivand S, Shih JH, Rais-Bahrami S, et al. A Magnetic Resonance Imaging-Based Prediction Model for Prostate Biopsy Risk Stratification. JAMA Oncol, 2018, 4(5):678-685. doi:10.1001/jamaoncol.2017.5667.
pmid: 29470570 |
[21] | Liu X, Thompson J, Dong H, et al. Digital adherence technologies to improve tuberculosis treatment outcomes in China: a cluster-randomised superiority trial. Lancet Glob Health, 2023, 11(5):e693-e703. doi:10.1016/S2214-109X(23)00068-2. |
